PRICE MATCH GUARANTEE
| 4 HOUR RATE | 24 HOUR RATE | 7 DAY RATE |
| $395.00 | $395.00 | $1580.00 ($226 per day) |
Price includes GST
Customers will be contacted on completion of online booking to confirm availability.
Please Note:- Delivery and /or Pick Up can be arranged for an extra Fee. Call 1800 776 447
ITEMS INCLUDED
ITEMS EXCLUDED
EXTRA ITEMS AVAILABLE ON REQUEST
| Terms & Conditions *All Excavators require a $400.00 Security Bond *Security Bond will Refunded on completion of Hire, after Excavator has been inspected and No Damage has occurred *Charges will apply for all damages to equipment/vehicles *All Excavators must be refueled on return *Cleaning Fee may apply if Excavator is returned in an unsatisfactory condition |
| Net Power | 17.6 kW |
| Engine Model | C1.1 Turbo |
| Net Power - 2,400 rpm - ISO 9249, 80/1269/EEC | 17.6 kW |
| Bore | 77 mm |
| Displacement | 1.1 l |
| Emissions | Meets U.S. EPA Tier 4 Final and EU Stage V emission standards. |
| Stroke | 81 mm |
| Gross Power - 2,400 rpm - SAE J1995:2014 | 18.4 kW |
| Operating Weight | 3050 kg |
| Minimum Operating Weight with Canopy* | 2560 kg |
| Maximum Operating Weight with Canopy** | 2925 kg |
| Minimum Operating Weight with Cab* | 2680 kg |
| EU: CE Plate Weight with Canopy*** | 2695 kg |
| EU: CE Plate Weight with Cab*** | 2800 kg |
| Note (2) | **Maximum Weight is based on steel tracks, operator, full fuel tank, long stick, blade, bucket and extra counterweight. |
| Note (1) | *Minimum Weight is based on rubber tracks, operator, full fuel tank, standard stick, blade, bucket and no extra counterweight. |
| Maximum Operating Weight with Cab** | 3050 kg |
| Note (3) | ***CE Plate Weight is based on the most common EU configuration. Includes 75 kg (165 lb) operator and full fuel tank and excludes bucket. |
| Long Stick | 15 kg |
| Steel Tracks | 100 kg |
| Cab | 125 kg |
| Counterweight (extra) | 250 kg |
| Counterweight (light) | 100 kg |
| Ground Pressure - Maximum Weight | 29 kPa |
| Ground Pressure - Minimum Weight | 24.2 kPa |
| Travel Speed - Low | 2.6 km/h |
| Gradeability - Maximum | 30 degrees |
| Maximum Traction Force - High Speed | 15.6 kN |
| Travel Speed - High | 4.5 km/h |
| Maximum Traction Force - Low Speed | 26.8 kN |
| Hydraulic System | 35 l |
| Hydraulic Tank | 18 l |
| Fuel Tank | 45 l |
| Engine Oil | 4 l |
| Cooling System | 4 l |
| Digging Force - Stick - Standard | 13.8 kN |
| Auxiliary Circuit - Primary - Pressure | 245 bar |
| Operating Pressure - Swing | 176 bar |
| Auxiliary Circuit - Secondary - Flow | 25 l/min |
| Auxiliary Circuit - Primary - Flow | 65 l/min |
| Auxiliary Circuit - Secondary - Pressure | 245 bar |
| Operating Pressure - Equipment | 245 bar |
| Digging Force - Stick - Long | 12.3 kN |
| Digging Force - Bucket | 23.3 kN |
| Operating Pressure - Travel | 245 bar |
| Pump Flow at 2,400 rpm | 100 l/min |
| Type | Load Sensing Hydraulics with Variable Displacement Piston Pump |
| Note | Flow and pressure are not combinable. Under load, as flow rises pressure goes down. |
| Machine Swing Speed | 9 r/min |
| Boom Swing - Left | 75 Degrees |
| Boom Swing - Right | 50 Degrees |
| Height | 320 mm |
| Width | 1570 mm |
| Top Guard | ISO 10262:1998 (Level I) |
| Tip Over Protective Structure (TOPS) | ISO 12117:1997 |
| Roll Over Protective Structure (ROPS) | ISO 12117-2:2008 |
| Operator Sound Pressure (ISO 6396:2008) | 78 dB(A) |
| Average Exterior Sound Pressure (ISO 6395:2008) | 94 dB(A) |
| Note | European Union Directive “2000/14/EC” |
| Overall Shipping Length* | 4240 mm |
| Boom In Reach | 1710 mm |
| O/A Shipping Height | 2480 mm |
| Swing Bearing - Height | 560 mm |
| Stick Length | 1060 mm |
| Maximum Reach | 4660 mm |
| Maximum Dump Clearance | 2950 mm |
| Maximum Dig Height | 4270 mm |
| Tail Swing without Counterweight | 775 mm |
| Tail Swing with Extra Counterweight | 890 mm |
| Boom Swing - Right | 830 mm |
| O/A Undercarriage Length | 2010 mm |
| Vertical Wall | 1870 mm |
| Note | *Overall Shipping Length depends on blade position during shipment. |
| Maximum Reach - Ground Level | 4510 mm |
| Dig Depth | 2510 mm |
| Track Belt/Shoe Width | 300 mm |
| Maximum Blade Height | 395 mm |
| Maximum Blade Depth | 515 mm |
| Boom Swing - Left | 605 mm |
| Ground Clearance | 310 mm |
| Boom Height - Shipping Position | 1560 mm |
| Tail Swing - with Light Counterweight | 845 mm |
| Dig Depth | 2710 mm |
| Boom Height - Shipping Position | 1650 mm |
| Boom Swing - Right | 830 mm |
| Maximum Reach - Ground Level | 4710 mm |
| Maximum Blade Height | 395 mm |
| Maximum Reach | 4850 mm |
| Boom Swing - Left | 605 mm |
| Maximum Blade Depth | 515 mm |
| O/A Shipping Height | 2480 mm |
| Maximum Dig Height | 4390 mm |
| Stick Length | 1260 mm |
| Tail Swing without Counterweight | 775 mm |
| Boom In Reach | 1730 mm |
| Maximum Dump Clearance | 3070 mm |
| Swing Bearing - Height | 560 mm |
| Vertical Wall | 2050 mm |
| O/A Undercarriage Length | 2010 mm |
| Ground Clearance | 310 mm |
| Track Belt/Shoe Width | 300 mm |
| Overall Shipping Length* | 4280 mm |
| Note | *Overall Shipping Length depends on blade position during shipment. |
| Tail Swing - with Extra Counterweight | 890 mm |
| Track Width | 1570 mm |
| Tail Swing - with Light Counterweight | 845 mm |
| Recyclability | 95% |
